Product Family
SUNSEE-AMERY Series
48V split-phase inverter family designed for 120VAC / 240VAC applications with dual MPPT and on/off-grid operation.
Split-Phase
48V split-phase inverter for backup-oriented markets
48V split-phase inverter family designed for 120VAC / 240VAC applications with dual MPPT and on/off-grid operation.
Highlights
- 120VAC / 240VAC split-phase output
- On-grid and off-grid support
- Parallel support up to 6 units
- Dual MPPT for more flexible PV input
Power Variants
4.2kW and 6.2kW
Battery Voltage
48V
Output Type
120VAC / 240VAC split-phase
Parallel Units
Up to 6
PV Input
2 x 3kW / 2 x 5kW
Protection Rating
IP20 indoor
Source and Boundary
Product information requires final model confirmation
SUNSEE-AMERY 4.2K / 6.2K product specification sheet
The two rated power variants, 48V battery input, 120/240Vac split-phase output, dual MPPT and six-unit parallel limit follow the product sheet.
Confirm charging settings, battery communication and market approval requirements before order placement.
Technical sheet supplied with the selected split-phase project configuration.
Quotation confirmation
Provide destination market, required capacity and system application so our team can confirm the matched model, brand scope and supporting documentation.
Start product inquiryApplication Fit
Application areas covered by this product family, subject to final model and system compatibility confirmation.
Residential backup systems
North American split-phase projects
Small hybrid systems
Flexible home solar deployment
Model Matrix
Compare the main variants available within this family.
4.2K
Compact split-phase option
6.2K
Higher-output split-phase option
Selection Guide
Key points for model comparison, system matching and quotation preparation.
Best Fit
A split-phase inverter family suited to customers who need residential-style voltage output with hybrid flexibility.
System Match
Best suited to home storage, backup systems and split-phase market requirements.
Selection Parameters
Battery platform, split-phase compatibility, PV input and parallel operation define system fit.
Request SUNSEE-AMERY Series
Send your destination market, capacity requirement, installation context and any document requirements for model confirmation and quotation.
